IoT-Line Counting Scale KERN CKE 6K0.02
Available from stock

Easy to use, self-explanatory counting scale with laboratory accuracy, counting resolution 300.000 points

List price
550.00 €

Weighing capacity

6000 g

Readability

0.02 g

Counting resolution

300000

Minimum piece weight

200 mg

Net weight

6.5 kg

Platform size

340×240 mm

Standard Option
Description
  • Precise, intuitive to use and digital – with our counting scales you can accelerate your annual stock taking processes and thus save time and money
  • Self-explanatory, graphic control panel, the workings steps can be understood immediately, even without operating instructions
    - no learning time = reduces costs
    - ideal for untrained users
    - visualised process avoids operating errors
  • The 4 steps are carried out from left to right:
    Place the empty container onto the weighing plate and tare by pressing the TARE key
    Place the reference quantity for the goods to be counted into the container (5, 10, 20 or any number of pieces)
    Confirm the selected reference quantity by pressing the key (5, 10, 20 or any number of pieces)
    Pour in the goods to be counted. The number of pieces will immediately be shown in the display
  • Precise counting: The automatic reference weight optimisation of reference weight gradually improves the average piece weight value
  • KERN Universal Port (KUP): permits the connection of an external KUP interface adapter, such as, for example, RS-232, USB, Bluetooth, WiFi or Ethernet, for the exchange of data and control commands, without any installation outlay
  • KERN Communication Protocol (KCP): The KCP permits searching and remote control of the balance using external control devices or computers
  • Two balances in one: Changes from counting mode to weighing mode at the touch of a key
  • Protective working cover included with delivery
Specifications

Article codes, product groups & Status information

Model article-code
:
CKE 6K0.02
Model-Serie
:
CKE
Assortment
:
KERN
Product Type
:
Industrial scales
Product group
:
Counting scales
Product usage type
:
Main article
EAN code (Model)
:
4045761357501
Predecessor Model
:
CKE 6K0.02-2019a; CKE 6K0.02-2022a
Planned start date
:
2023-1HJ
Customs tariff number
:
90160010
Product status
:
Active
CE Label
:
Yes

Technical data - Measuring system

Calibration method
:
Adjusting with external weight
Linearity
:
± 0.2 g
Readability
:
0.02 g
Recommended adjusting weight
:
6 kg (F1)
Repeatability
:
0.04 g
Resolution
:
300.000
Stabilisation time under laboratory conditions
:
3 s
Warm up time
:
120 min
Weighing system
:
Strain gauge
Weighing units
:
Dwt;ffa;g;gn;kg;lb;oz;ozt;PCS

Technical data - Primary

Weighing capacity
:
6000 g
Readability
:
0.02 g
Counting resolution
:
300000
Minimum piece weight
:
200 mg
Net weight
:
6.5 kg
Platform size
:
340×240 mm

Technical data - Display

Display height
:
25 mm
Backlight
:
Yes

Technical data - Environmental conditions

Maximum humidity
:
80 %
Maximum operating temperature
:
40 °C
Minimum ambient temperature
:
-10 °C

Technical data - Packing & Shipping

Packaging component - by weight - cardboard
:
550 g
Packaging component - by weight - plastics
:
550 g
Delivery time
:
1 d
Dimensions packaging (W×D×H)
:
470×470×190 mm
Gross weight
:
8 kg
Net weight
:
7 kg
Shipping method
:
Parcel service

Technical data - Construction

Casing material
:
ABS plastic
Dimension housing (W×D×H)
:
350×390×120 mm
Material weighing plate
:
Stainless steel
Bubble Level
:
Yes
Revolving screw feet
:
Yes
Weighing surface (d)
:
340×240 mm
Dimensions of weighing plate (W×D)
:
340×240 mm

Technical data - Power supply

Battery
:
4×1.5 V AA
Operating time
:
20 h
Mains adapter/adapter included
:
CH;EURO;UK;US
Charging time
:
8 h
Input Voltage
:
100 V - 240 V AC, 50 / 60 Hz
Operating time (Backlight off)
:
48 h
Rechargeable battery
:
Rchrg. battery optional - intern
Interfaces
:
Bluetooth BLE (v4.0) (optional);Ethernet (optional);KUP;RS-232 (optional);USB-Device (optional);WLAN (optional)

Technical data - Counting data

Counting resolution
:
300000
Mininum piece weight at piece counting (Laboratory)
:
20 mg
Minimum piece weight
:
200 mg

Responsible Persons

Product manager
:
Steffen Hofmann

Prices & Discounts

List price
:
550.00 €
Warranty
:
36 mon

Optional Services

DAkkS Calibration
:
963-128
Software

SCD-4.0-DL

210.00 €

Flexible recording or transfer of measurements, particularly to Microsoft® Excel or Access

SCD-4.0-PRO-DL

380.00 €

Flexible recording or transfer of measurements, particularly to Microsoft® Excel or Access

SET-17

1,320.00 €

EasyTouch PrePack – checking pre-packed items

SET-01

990.00 €

EasyTouch Base – Basic programme

SET-21

429.00 €

EasyTouch Formulation – Recipe function

SET-22

242.00 €

EasyTouch Difference – Difference weighing e.g. the growth of cell cultures

SET-31

341.00 €

EasyTouch Tolerance - Tolerance weighing function

SET-32

341.00 €

EasyTouch Count – Piece-counting function

SET-33

341.00 €

EasyTouch Target Count – Target-counting function

SET-04

220.00 €

EasyTouch Density – Density determination function

SET-05

67.00 €

EasyTouch Dynamic – Dynamic weighing and Animal weighing function

SET-06

208.00 €

EasyTouch Classification – Classification function

SET-07

79.00 €

EasyTouch Variable – Free Variable

SET-08

220.00 €

EasyTouch Take-out – The take-out function enables negative weighing out of a source container

SET-10

1,400.00 €

EasyTouch Save Server – Central weighing data memory

SET-11

671.00 €

EasyTouch Safety - Precision and Safety function

SET-16

341.00 €

EasyTouch Batch and Statistics – Batch measuring with statistical analysis and batch print function

SET-14

385.00 €

EasyTouch Individual Print - printouts which can be personalised

SET-28

132.00 €

EasyTouch Customization Service – Data interfaces and customised adaptations

SET-35

308.00 €

EasyTouch Assembly Count – Order picking, rapid, simple and error-free

SET-18

149.00 €

EasyTouch Container Master – Centralised container management

SET-46

99.00 €

EasyTouch Backup Scheduler – data backup and restore

SET-51

119.00 €

EasyTouch Audit Logs – for critical weighing processes

SET-411

90.00 €

EasyTouch hotkeys - shortcut keys and external switches

SET-52

990.00 €

EasyTouch Inventory – stock-taking: Efficient and correct
