Counting Scale KERN CPB 15K0.2N
Available from stock

Professional model with counting resolution 60.000 points

List price
290,00 €

Weighing capacity

15 kg

Readability

0,0002 kg

Counting resolution

60.000

Minimum piece weight

2,5 g

Net weight

3,3 kg

Platform size

295×225 mm

Standard Option
Description
  • Precise, intuitive to use and digital – with our counting scales you can accelerate your annual stock taking processes and thus save time and money
  • Precise counting: The automatic reference weight optimisation of reference weight gradually improves the average piece weight value
  • Programmable using numerical key pad:
    - required reference quantity
    - known reference weight
  • Three displays for weight display, reference weight, total pieces
  • Counting results memory: adds up all individual piece counts, result is shown in total weight and total pieces
  • Fill-to-target function: Target count or target weight can be programmed. When the target value is reached, this will be indicated by an audible signal
  • PRE-TARE function for manual subtraction of a known container weight, useful for checking fill-levels
  • High mobility: thanks to rechargeable battery operation (optional), compact, lightweight construction, it is suitable for the use in several locations (production, warehouse, dispatch department, etc.)
  • Two balances in one: Changes from counting mode to weighing mode at the touch of a key
  • Protective working cover included with delivery
Specifications

Article codes, product groups & Status information

Model article-code
:
CPB 15K2N
Model-Serie
:
CPB
Assortment
:
KERN
Product Type
:
Industrial scales
Product group
:
Counting scales
Product usage type
:
Main article
EAN code (Model)
:
4045761124387
Planned start date
:
2015-2HJ
Customs tariff number
:
84238129
Model Status
:
Active
CE Label
:
Yes
Country of Origin
:
CN

Technical data - Environmental conditions

Maximum humidity
:
80 %
Maximum operating temperature
:
40 °C
Minimum ambient temperature
:
0 °C
Minimum humidity
:
0 %

Responsible Persons

Product manager
:
Steffen Hofmann

Prices & Discounts

List price
:
290,00 €
List price, next year
:
285,00 €
Warranty
:
24 mon

Technical data - Primary

Weighing capacity
:
15 kg
Readability
:
0,0002 kg
Counting resolution
:
60.000
Minimum piece weight
:
2,5 g
Net weight
:
3,3 kg
Platform size
:
295×225 mm

Technical data - Display

Display height
:
20 mm
Backlight
:
Yes

Technical data - Power supply

Mains adapter/adapter included
:
CH;EURO;UK;US
Charging time
:
12 h
Input Voltage
:
100 V - 240 V, 50 / 60 Hz
Operating time (Backlight off)
:
90 h
Rechargeable battery
:
Rchrg. battery optional - intern
Interfaces
:
RS-232 standard

Technical data - Packing & Shipping

Packaging component - by weight - cardboard
:
533 g
Packaging component - by weight - styrofoam
:
533 g
Delivery time
:
1 d
Dimensions packaging (W×D×H)
:
370×450×210 mm
Gross weight
:
4,4 kg
Net weight
:
3,4 kg
Shipping method
:
Parcel service

Technical data - Construction

Casing material
:
Plastic
Dimension housing (W×D×H)
:
315×350×100 mm
Dimensions device (W×D×H)
:
315×350×125 mm
Material weighing plate
:
Stainless steel
Bubble Level
:
Yes
Revolving screw feet
:
Yes
Weighing surface (d)
:
295×225 mm
Dimensions of weighing plate (W×D)
:
295×225 mm

Technical data - Measuring system

Calibration method
:
Adjusting with external weight
Linearity
:
± 0,0008 kg
Readability
:
0,0002 kg
Recommended adjusting weight
:
10 kg (F2); 5 kg (F2)
Repeatability
:
0,0004 kg
Resolution
:
75.000
Stabilisation time under laboratory conditions
:
2 s
Tare range
:
15 kg
Warm up time
:
120 min
Weighing system
:
Strain gauge
Weighing units
:
Kg

Technical data - Counting data

Counting resolution
:
60.000
Mininum piece weight at piece counting (Laboratory)
:
250 mg
Minimum piece weight
:
2,5 g

Optional Services

DAkkS Calibration
:
963-128
Your KERN product specialist will be happy to help
