Pallet Scale KERN UID 600K-1M
Available from stock

Pallet scale with and a wide range of interfaces, verification optional

List price
1,220.00 €

Weighing capacity

600 kg

Readability

0.2 kg

Minimum load (Min)

4 kg

Net weight

44 kg

Standard Option Factory
Description
  • High mobility thanks to rechargeable battery operation (optional)
  • Display device: Protection against dust and water splashes IP65
  • Load support: steel, powder coated, 4 load cells, alloy steel, silicone-coated, protection against dust and water splashes IP67
  • The scale can be easily transported using rollers and a handle and does not require much storage space
  • Totalising of weights and piece counts
  • Searching and remote control of the balance using external control devices or computers with the KERN Communication Protocol (KCP). KCP is a standardised interface command structure for KERN balances and other instruments which allows you to recall and manage all relevant parameters and device functions. You can therefore simply connect KERN devices with KCP to computers, industrial control systems and other digital systems. In a large number of cases the KCP is compatible with the MT-SICS protocol
  • Thanks to interfaces such as RS-232 or USB, WiFi, Bluetooth, Ethernet (optional), the scale can easily be connected to existing networks. Data exchange between the scale, PC or printer
  • Protective working cover included with delivery
Specifications

Article codes, product groups & Status information

Model article-code
:
UID 600K-1M
Model-Serie
:
UID
Assortment
:
KERN
Product Type
:
Industrial scales
Product group
:
Pallet scales
Product usage type
:
Main article
EAN code (Model)
:
4045761230194
Planned start date
:
2020-1HJ
Customs tariff number
:
84238220
Product status
:
Active
CE Label
:
Yes

Technical data - Display

Display height
:
25 mm
Backlight
:
Yes

Technical data - Measuring system

Calibration method
:
Adjusting with external weight
Linearity
:
± 0.6 kg
Readability
:
0.2 kg
Recommended adjusting weight
:
600 kg (M1)
Repeatability
:
0.2 kg
Resolution
:
3.000
Tare range
:
-600 kg
Warm up time
:
10 min
Weighing units
:
G;HJ;kg;lb;oz;PCS;tJ
load cell connection
:
4-guide

Technical data - Primary

Weighing capacity
:
600 kg
Readability
:
0.2 kg
Minimum load (Min)
:
4 kg
Net weight
:
44 kg

Technical data - Power supply

Battery
:
No battery
Mains adapter/adapter included
:
EURO;UK;US
Charging time
:
3 h
Input Voltage
:
100V-240V AC 50/60Hz 0.4 Amax
Operating time (Backlight off)
:
43 h
Rechargeable battery
:
Rchrg. battery optional - intern

Technical data - Environmental conditions

Maximum humidity
:
95 %
Maximum operating temperature
:
40 °C
Minimum ambient temperature
:
-10 °C
Minimum humidity
:
10 %

Optional Services

DAkkS Calibration
:
963-130
Verification
:
965-230

Technical data - Verification

Verification value (e)
:
0.2 kg
Minimum Load Min
:
4 kg
Verification by KERN possible
:
Yes
Verification class
:
III

Technical data - Construction

IP protection indicator
:
IP65
IP protection load cell
:
IP67
Dimensions display casing (W×D×H)
:
268×115×80 mm
Material weighing plate
:
Steel, powder-coated
Bubble Level
:
Yes
Revolving screw feet
:
Yes
Weighing surface (d)
:
1195×840 mm
Dimensions of weighing plate (W×D)
:
1195×840 mm
Indicator cable length
:
5 m
Wall mount
:
Yes
Dimension weighing platform (W×D×H)
:
1195×840×110 mm

Technical data - Packing & Shipping

Packaging component - by weight - cardboard
:
420 g
Packaging component - by weight - wood
:
20580 g
Delivery time
:
2 d
Dimensions packaging (W×D×H)
:
1240×890×245 mm
Gross weight
:
65 kg
Net weight
:
44 kg
Shipping method
:
Freight

Responsible Persons

Product manager
:
Thomas Buchholz

Prices & Discounts

List price
:
1,220.00 €
Warranty
:
36 mon
Software

SET-17

1,320.00 €

EasyTouch PrePack – checking pre-packed items

SET-01

990.00 €

EasyTouch Base – Basic programme

SET-21

429.00 €

EasyTouch Formulation – Recipe function

SET-22

242.00 €

EasyTouch Difference – Difference weighing e.g. the growth of cell cultures

SET-31

341.00 €

EasyTouch Tolerance - Tolerance weighing function

SET-32

341.00 €

EasyTouch Count – Piece-counting function

SET-33

341.00 €

EasyTouch Target Count – Target-counting function

SET-04

220.00 €

EasyTouch Density – Density determination function

SET-05

67.00 €

EasyTouch Dynamic – Dynamic weighing and Animal weighing function

SET-06

208.00 €

EasyTouch Classification – Classification function

SET-07

79.00 €

EasyTouch Variable – Free Variable

SET-08

220.00 €

EasyTouch Take-out – The take-out function enables negative weighing out of a source container

SET-10

1,400.00 €

EasyTouch Save Server – Central weighing data memory

SET-11

671.00 €

EasyTouch Safety - Precision and Safety function

SET-16

341.00 €

EasyTouch Batch and Statistics – Batch measuring with statistical analysis and batch print function

SET-14

385.00 €

EasyTouch Individual Print - printouts which can be personalised

SET-28

132.00 €

EasyTouch Customization Service – Data interfaces and customised adaptations

SET-35

308.00 €

EasyTouch Assembly Count – Order picking, rapid, simple and error-free

SET-18

149.00 €

EasyTouch Container Master – Centralised container management

SET-46

99.00 €

EasyTouch Backup Scheduler – data backup and restore

SET-51

119.00 €

EasyTouch Audit Logs – for critical weighing processes

SET-411

90.00 €

EasyTouch hotkeys - shortcut keys and external switches
Your KERN product specialist will be happy to help
