Mobile Leeb Hardness Tester SAUTER HMO
Available from stock

Advanced features for professional applications

List price
2020.00 €

Max. HLx

960

Min. HLx

170

Hardness scales

HLD

Standard Option
Description
  • LCD touchscreen with touch pen
  • Automatic recognition of the impact (rebound) sensor connected to the SAUTER HMO
  • Mobility: In comparison with stationary table-top devices and testing devices with an internal sensor, using the SAUTER HMO offers the highest level of mobility and flexibility
  • All measurement directions possible (360°) by defining the direction of impact on the device
  • USB socket for connection to the printer and charging the batteries
  • Hardness test block for calibration included
  • Internal data memory for up to 500 values
  • Mini statistics function: Displays the measure value, the average value, the difference between the maximum and minimum values, date and time
  • Measurement value display: (B and C), Vickers (HV), Brinell (HB), Leeb (HL), tensile strength (MPa)
  • Automatic unit conversion: The measuring result is automatically converted into all specified hardness units
  • Delivered in a robust carrying case
Specifications

Article codes, product groups & Status information

Model article-code
:
HMO
Model-Serie
:
HMO
Assortment
:
Sauter
Product Type
:
Hardness measurement
Product group
:
Hardness testers (Leeb)
Product usage type
:
Main article
EAN code (Model)
:
4045761139664
Predecessor Model
:
HMO-2019a
Planned start date
:
2012-1HJ
Customs tariff number
:
90241040
Product status
:
Active
CE Label
:
Yes

Technical data - Counting data

Memory
:
Yes

Prices & Discounts

List price
:
2020.00 €
Warranty
:
36 mon

Technical data - Primary

Max. HLx
:
960
Min. HLx
:
170
Hardness scales
:
HLD

Technical data - Power supply

Power supply
:
Battery & Power supply
Battery type
:
Li-Ion

Technical data - Functions

Averaging
:
Yes
Automatic Sensor detection
:
Yes
360° Measuring
:
Yes

Responsible Persons

Product manager
:
Dietmar Paul

Optional Services

Factory calibration
:
961-131

Technical data - Construction

Dimension housing (W×D×H)
:
24×83×135 mm
Material housing
:
Plastic

Technical data - Display

Display type
:
LCD touch

Technical data - Measuring system

Readability (HLx)
:
1
Tolerance (% from Max.)
:
1%
Units
:
HB;HL;HRB;HRC;HV;MPa
Test item - weight - minimum
:
3 kg
Measuring probe - length
:
14,6 cm
Measuring probe - diameter
:
2 cm

Technical data - Packing & Shipping

Packaging component - by weight - cardboard
:
670 g
Packaging component - by weight - styrofoam
:
400 g
Packaging component - by weight - foam
:
40 g
Delivery time
:
1 d
Dimensions packaging (W×D×H)
:
450×340×165 mm
Gross weight
:
6 kg
Net weight
:
4.6 kg
Shipping method
:
Parcel service
UN number
:
Li-Ion, packed with device (UN 3481, Packing Instruction #7, Lithium ion batteries in compliance with Section II of PI 967)
Software
