SAUTER spring balance 283-422
Available from stock
Precise, mechanical force gauge in robust aluminium housing with Newton readout
List price
132.00 €
Technical Datasheet
Max. Force
25 N
Readability
0.2 N
| Standard | Option | ||
|---|---|---|---|
 |
 |
Description
- Aluminium scale tube: robust, long service life, handy
- Newton scale: Measuring result displayed in Newton
- Double scale: For fast or precise recording of the measurement result
- Compressive force measurement: possible using an optional pressure set
- Carrying handle as standard
- High precision: Backlash-free spring bearing with integrated tare screw for highly-precise adjustment
- Non-fatigue stainless steel spring
- Clip loop which can be freely rotated of the lower suspension bracket by 360°
- High-quality workmanship: Wear-resistant, colour-anodised precision scale with high resolution for accurate readability of the measuring result
Specifications
Article codes, product groups & Status information
Model article-code
:
283-422
Model-Serie
:
283
Assortment
:
Sauter
Product Type
:
Force measurement
Product group
:
Mechanical force gauges & spring balances
Product usage type
:
Main article
EAN code (Model)
:
4045761002210
Planned start date
:
2009-1HJ
Customs tariff number
:
90248000
Product status
:
Active
Technical data - Primary
Max. Force
:
25 N
Readability
:
0.2 N
Technical data - Functions
Peak-Function
:
Yes
Technical data - Packing & Shipping
Packaging component - by weight - plastics
:
0 g
Delivery time
:
1 d
Dimensions packaging (W×D×H)
:
230×26×17 mm
Gross weight
:
0.05 kg
Net weight
:
0.05 kg
Shipping method
:
Parcel service
UN number
:
No dangerous goods
Technical data - Measuring system
Units
:
N
Tolerance (% from Max.)
:
0.3%
Force direction
:
Tension
Responsible Persons
Product manager
:
Dietmar Paul
Prices & Discounts
List price
:
132.00 €
Warranty
:
24 mon
Optional Services
Factory calibration
:
961-161O
Factory calibration push only
:
961-161O
Accessories
Spare Parts
No records found
Services
Software
No records found
