Display Devices KERN KFN-TM
Available from stock

Stainless steel display device with IP65 protection and superior display size and optional analogue output for controlling systems (PLC) etc.

List price
360,00 €

Net weight

2,5 kg

Standard
Factory
Description
  • Adjusting program CAL for quick setting
  • Weighing with tolerance range (checkweighing)
  • Totalising
  • Piece counting with reference: Possible reference counts: 10, 20, 50, 100, 200
  • Hold function: When the weighing conditions are unstable, a stable weight is calculated determining an average value
  • Integrated KERN Communication Protocol (KCP), ideal for connecting an Merchandise Management or ERP system
  • EC type approval: yes
  • Display device: stainless steel, protection against dust and water splashesIP65
  • Benchtop stand for display device incl.
  • Wall mount for display device, standard
Specifications

Article codes, product groups & Status information

Model article-code
:
KFN-TM
Model-Serie
:
KFN
Assortment
:
KERN
Product Type
:
Industrial scales
Product group
:
Display devices
Product usage type
:
Main article
EAN code (Model)
:
4045761194427
Predecessor Model
:
KFN-TM-2.016a
Planned start date
:
2017-2HJ
Customs tariff number
:
84239010
Model Status
:
Active
CE Label
:
Yes
Country of Origin
:
CN

Responsible Persons

Product manager
:
Thomas Buchholz

Prices & Discounts

List price
:
360,00 €
Warranty
:
24 mon

Technical data - Primary

Net weight
:
2,5 kg

Technical data - Display

Display height
:
52 mm
Backlight
:
Yes

Technical data - Power supply

Mains adapter/adapter included
:
CH;EURO;UK;US
Charging time
:
12 h
Input Voltage
:
110 V - 230 V AC
Operating time (Backlight off)
:
35 h
Interfaces
:
Analog (0 - 10 V) (optional, factory);Analog (4 - 20 mA) (optional, factory);Bluetooth BTC (v2.0) (optional, factory);RS-232 (optional, factory)

Technical data - Packing & Shipping

Packaging component - by weight - cardboard
:
350 g
Packaging component - by weight - styrofoam
:
350 g
Delivery time
:
1 d
Dimensions packaging (W×D×H)
:
330×250×210 mm
Gross weight
:
3,2 kg
Net weight
:
2,6 kg
Shipping method
:
Parcel service
UN number
:
2800

Technical data - Construction

IP protection indicator
:
IP65
Dimensions display casing (W×D×H)
:
320×200×250 mm
Wall mount
:
Yes
Material casing
:
Stainless steel

Technical data - Measuring system

Calibration method
:
Adjusting with external weight
Resolution (non verified)
:
30.000
Resolution (verified)
:
6.000
Weighing units
:
Kg
Linearity (in dots)
:
3
Number of weighing ranges
:
2

Technical data - Environmental conditions

Maximum operating temperature
:
40 °C
Minimum ambient temperature
:
-10 °C

Technical data - Verification

Verification by KERN possible
:
Yes
Verification class
:
III
