Supporting Bar KERN 347-445-100
Available from stock

Supporting bar, OIML Class M1, 10 g, aluminium

List price
56.00 €

Nominal value

10 g

Tolerance (OIML)

2 mg

Standard Option
Description
  • for fixing slotted weights
  • The beam bar is tapered near the hook so that slotted weights can be hooked and unhooked easily. During use, the weights remain securely in place and are protected against accidentally falling off.
  • Own weight beam bar 10 g

  • Maximum total load 200 g (is exclusive of the own weight of the beam bar, e.g. the maximum possible total weight is calculated from “Maximum total load” + “own weight beam bar”)

  • Largest slotted weight possible 100 g
Specifications

Article codes, product groups & Status information

Model article-code
:
347-445-100
Model-Serie
:
347
Assortment
:
KERN
Product Type
:
Test weights
Product group
:
OIML M1 Test weights
Product usage type
:
Main item;Accessories/Services
EAN code (Model)
:
4045761009158
Planned start date
:
2004-1HJ
Customs tariff number
:
84239090
Product status
:
Active

Technical data - Primary

Nominal value
:
10 g
Tolerance (OIML)
:
2 mg

Technical data - Packing & Shipping

Packaging component - by weight - plastics
:
0 g
Delivery time
:
1 d
Dimensions packaging (W×D×H)
:
13×13×114 mm
Gross weight
:
0.05 kg
Net weight
:
0.05 kg
Shipping method
:
Parcel service

Technical data - Construction

Material
:
Aluminium

Technical data - Measuring system

Nominal value
:
10 g
OIML class
:
M1
OIML conform
:
Yes
Tolerance (OIML)
:
2 mg
Density (kg/m³)
:
8400
Volume (cm³)
:
1,1905

Responsible Persons

Product manager
:
Christoph Sauter

Prices & Discounts

List price
:
56.00 €
Warranty
:
24 mon

Optional Services

DAkkS Calibration
:
962-634
Spare Parts
No records found
Software
No records found
Downloads
Document name Language
Declaration of Conformity (OIML R111) English
Operating instructions (Handling) German
Operating instructions (Tips) German English French Italian Spanish
Technical Datasheet German English French Italian Spanish
Product brochure German English French Italian Spanish
