Manual Shore Test Stand SAUTER TI-DL
Available from stock

Lever operated test stand for hardness testing with base plate made of glass

List price
445,00 €

Hardness scales

Shore D

Standard
Description
  • For Shore hardness testing of plastics, leather etc.
  • Glass plate: high measurement accuracy by means of superior hardness of the glass plate
  • Mechanical construction: Robust design enables accurate measuring movements
  • Level adjustment: For the precise levelling of the base plate, e.g. for the correction of inhomogeneous test objects
  • with exchangeable longer column for use with digital hardness tester HD
  • Hardness tester is not included with delivery
  • Operation:
    1. The SAUTER hardness testing device HDD is fitted in a suspended position
    2. The test object is placed on the round testing table right under the durometer measuring tip
    3. By pressing the lever down, the test weight will be released, and this then presses the measuring tip into the test object with its own weight (see test force hardness measurement)
  • The accuracy of the displayed result is about 25 % higher than in a manual operated test
Specifications

Article codes, product groups & Status information

Model article-code
:
TI-DL
Model-Serie
:
TI
Assortment
:
Sauter
Product Type
:
Hardness measurement
Product group
:
Hardness testers (Shore)
Product usage type
:
Main item;Accessories/Services
EAN code (Model)
:
4045761179172
Planned start date
:
2012-1HJ
Customs tariff number
:
90248000
Model Status
:
Active
Country of Origin
:
CN

Technical data - Primary

Hardness scales
:
Shore D

Technical data - Measuring system

Test force Hardness measurement
:
50 N

Technical data - Packing & Shipping

Packaging component - by weight - cardboard
:
750 g
Packaging component - by weight - styrofoam
:
750 g
Delivery time
:
1 d
Dimensions packaging (W×D×H)
:
355×255×180 mm
Gross weight
:
11 kg
Net weight
:
9 kg
Shipping method
:
Parcel service
UN number
:
No dangerous goods

Technical data - Construction

Material housing
:
Coated metal

Technical data - Environmental conditions

Maximum storage temperature
:
40 °C
Minimum storage temperature
:
-10 °C

Responsible Persons

Product manager
:
Dietmar Paul

Prices & Discounts

List price
:
445,00 €
Warranty
:
24 mon
Accessories
No records found
Services
No records found
Software
No records found
